Specifications
Family: Cam Lever Couplings
Type: Part E
Style: Polypropylene
Size: ¾"
Weight 0.062 lbs
Double O-rings in stem area for extra sealing protection.
EPDM O-rings to handle most fertilizers and many chemicals.
Interlocking body and end plate to allow easy thread connection when installing valves.
Maximum operating pressure 300 P.S.I. at 70°:F.
Precision molded in glass reinforced polypropylene, for strength and chemical resistance.
PTFE seats for smooth operation and proper sealing characteristics.
Complete series of ½", ¾", 1", 1¼", 1½", 2", 3" and 4" NPT thread.
Durable: Polypropylene is glass filled for rugged strength and durability.
Economical and superior in performance.
Most complete line of polypropylene couplings available.
Maximum operating pressure 300 psi
Precision molded: insures: uniform and accurate fit.
Smooth operating: finger rings are designed for easy opening of cam levers.
Stainless steel rings, arms: pins.
Versatile: interchangeable with all types of cam lever couplers.
WARNING: Couplings should not be disconnected under pressure or with liquid in the line.
Carrico Part Number: PM075E
